Fast Recovery Diodes
(Hockey PUK Version), 600 A
SD603C..C Series
Vishay High Power Products
FEATURES
• High power FAST recovery diode series
• 1.0 to 2.0 µs recovery time
• High voltage ratings up to 2200 V
• High current capability
• Optimized turn-on and turn-off characteristics
• Low forward recovery
• Fast and soft reverse recovery
• Press PUK encapsulation
• Case style conform to JEDEC B-43
• Maximum junction temperature 125 °C
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Snubber diode for GTO
• High voltage freewheeling diode
• Fast recovery rectifier applications
PRODUCT SUMMARY
I
F(AV)
600 A
B-43
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST
CONDITIONS
VALUES
UNITS
I
F(AV)
600
A
T
hs
55
°C
I
F(RMS)
942
A
T
hs
25
°C
I
FSM
50 Hz
8320
A
60 Hz
8715
I
2
t
50 Hz
346
kA
2
s
60 Hz
316
V
RRM
Range
400 to 2200
V
t
rr
1.0 to 2.0
µs
T
J
25
°C
T
J
- 40 to 125
