Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272 Intellimod™ Module
Three Phase
IGBT Inverter Output
150 Amperes/1200 Volts
437
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
□
Complete Output Power
Circuit
□
Gate Drive Circuit
□ Protection Logic
– Short Circuit
– Over Temperature
– Under Voltage
Applications:
□ Inverters
□ UPS
□
Motion/Servo Control
□
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM150CVA120 is a 1200V,
150 Ampere Intellimod™ Intelligent
Power Module.
Type Current Rating V
CES
Amperes Volts (x 10)
PM 150 120
Outline Drawing and Circuit Diagram
Dimensions Inches Millimeters
A 5.31 135.0
B 4.33 110.0
C 1.14 +0.04/-0.02 29.0 +1.0/-0.5
D 4.74 ± 0.010 120.5 ± 0.25
E 3.76
±
0.010 95.5
±
0.25
F 0.16 4.0
G 1.14 29.0
H 0.41 10.4
J 1.10 28.0
K 3.82 97.0
L 0.55 14.0
M 0.59 15.0
N 0.88 22.25
Dimensions Inches Millimeters
P 0.29 7.25
Q 1.98 50.25
R 1.03 26.25
S M5 Metric M5
T 0.22 Dia. Dia. 5.5
U 0.56
±
0.010 14.1
±
0.25
V 1.72
±
0.012 43.57
±
0.3
W 0.57 ± 0.012 14.6 ± 0.3
Y 1.04 26.5
Z 0.10 ± 0.010 2.54 ± 0.25
AA 0.137
±
0.010 3.49
±
0.25
BB 0.02 SQ 0.64 SQ
CC 0.12 +0.04/-0.02 3.0 +1.0/-0.5
OUT
TEMP
Si
GND
VN1 WN VNC
F
O
NC
N W V U P
Rf O
V CC
F O
IN
TH
GND
OUT
Si
GND
VN
V CC
F O
IN
GND
OUT
Si
GND
UN
V CC
F O
IN
GND
OUT
Si
GND
V
WP1 W
P
W
FO
V
FO
U
FO
V
WPC
V CC
F O
IN
GND
OUT
Si
GND
V
VP1 V
P
V
VPC
V CC
F O
IN
GND
OUT
Si
GND
V
UP1 U
P
V
UPC
V CC
F O
IN
GND
Rf O = 1.5k OHM
TERMINAL CODE
1. W FO
2. V WPC
3. W P
4. V WP1
5. V FO
6. V VPC
7. V P
8. V VP1
9. U FO
10. V UPC
11. U P
12. V UP1
13. NC
14. F
O
15. VNC
16. VN1
17. UN
18. VN
19. WN
S NUTS (5 TYP.)
T (4 TYP.)
D
A
B K E
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
17 18 19
N P
U V W
J
TYP.
N
V
U
R
P
U
M
L - TYP.
M
Q
C G
F
H
Y
W
Z - TYP.
AA - TYP.
BB SQ PIN - TYP.
(19 PLACES)
CCØ
(4 PLACES)
DETAIL A
SEE
DETAIL A
PM150CVA120
