HFA32PA120CPbF

Vishay High Power Products

HEXFRED

®

Ultrafast Soft Recovery Diode, 2 x 16 A

ORDERING INFORMATION TABLE

1

3
4

5

2

3

4

5

6

-

HEXFRED

®

family

-

Process designator: A = Subs. electron irradiated

B = Subs. platinum

-

Current rating (32 = 32 A)

-

Package outline (PA = TO-247, 3 pins)

-

Voltage rating (120 = 1200 V)

-

Configuration (C = Center tap common cathode)

Device code

5

1

3

2

4

6

7

HF

A

32

PA

120

C

PbF

7

-

None = Standard production

PbF = Lead (Pb)-free
