Standard Recovery Diodes
(Stud Version), 380 A
SD300N/R Series
Vishay Semiconductors
FEATURES
• Wide current range
• High voltage ratings up to 3200 V
• High surge current capabilities
• Stud cathode and stud anode version
• Standard JEDEC types
• Compression bonded encapsulations
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Converters
• Power supplies
• Machine tool controls
• High power drives
• Medium traction applications
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
F(AV)
380 A
DO-205AB (DO-9)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS
SD300N/R
UNITS
16 to 20 25 to 32
I
F(AV)
380 A
T
C
100 70 °C
I
F(RMS)
595 425
A
I
FSM
50 Hz 6050
60 Hz 6335
I 2 t
50 Hz 183
kA 2 s
60 Hz 167
V
RRM
Range 1600 to 2000 2500 to 3200 V
T
J
- 40 to 180 - 40 to 150 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
SD300N/R
16 1600 1700
15
20 2000 2100
25 2500 2600
28 2800 2900
32 3200 3300
