Document Number: 94410 For technical questions, contact: [email protected] www.vishay.com
Revision: 06-May-08 1
Phase Control Thyristors
(Hockey PUK Version), 960 A
ST380CPbF Series
Vishay High Power Products
FEATURES
• Center amplifying gate
• Metal case with ceramic insulator
• International standard case TO-200AB (E-PUK)
• Low profile hockey PUK to increase
current-carrying capability
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
960 A
TO-200AB (E-PUK)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
960 A
T
hs
55 °C
I
T(RMS)
1900 A
T
hs
25 °C
I
TSM
50 Hz 15 000
A
60 Hz 15 700
I 2 t
50 Hz 1130
kA 2 s
60 Hz 1030
V
DRM
/V
RRM
400/600 V
t
q
Typical 100 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM REPETITIVE PEAK
AND OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST380C..C
04 400 500
50
06 600 700
