PM300DVA120
Intellimod™ Module
Single Phase IGBT Inverter Output
300 Amperes/1200 Volts
450
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings,
T
j
= 25
°
C unless otherwise specified
Characteristics
Symbol
PM300DVA120
Units
Power Device Junction Temperature
T
j
-20 to 150
°
C
Storage Temperature
T
stg
-40 to 125
°
C
Case Operating Temperature
T
C
-20 to 100
°
C
Mounting Torque, M6 Mounting Screws (Typical)
—
26
in-lb
Mounting Torque, M6 Main Terminal Screws (Typical)
—
26
in-lb
Module Weight (Typical)
—
720
Grams
Supply Voltage (Applied between C1-E2)
V
CC(surge)
1000
Volts
Supply Voltage Protected by SC (V
D
= 13.5 ~16.5V, Inverter Part, T
j
= 125
°
C Start)
V
CC(prot.)
800
Volts
Isolation Voltage, AC 1 minute, 60Hz Sinusoidal
V
RMS
2500
Volts
Control Sector
Supply Voltage Applied between (V
P1
-V
PC
, V
N1
-V
NC
)
V
D
20
Volts
Input Voltage Applied between (C
P1
-V
PC
, C
N1
-V
NC
)
V
CIN
10
Volts
Fault Output Supply Voltage (Applied between F
PO
-V
PC
, F
NO
-V
NC
)
V
FO
20
Volts
Fault Output Current (Sink Current at F
O
Terminals)
I
FO
20
mA
IGBT Inverter Sector
Collector-Emitter Voltage (V
D
= 15V, V
CIN
= 5V)
V
CES
1200
Volts
Collector Current,
±
(T
C
= 25
°
C)
I
C
300
Amperes
Peak Collector Current,
±
(T
C
= 25
°
C)
I
CP
600
Amperes
Collector Dissipation (T
C
= 25
°
C)
P
C
1380
Watts
