MITSUBISHI FAST RECOVERY DIODE MODULE
RM600DY-66S
HIGH POWER SWITCHING USE
INSULATED TYPE
ABSOLUTE MAXIMUM RATINGS
(Tj = 25
°
C)
Voltage class
V
RRM
V
RSM
V
R(DC)
Repetitive peak reverse voltage
Non-repetitive peak reverse voltage
Reverse DC voltage
Symbol
Item
V
V
V
Unit
A
A
A
2
s
°
C
°
C
V
N · m
N · m
kg
I
DC
I
FSM
I
2t
T
j
T
stg
V
iso
—
—
Output DC current
Surge (non-repetitive) forward current
I
2
t for fusing
Junction temperature
Storage temperature
Isolation Voltage
Mounting torque
Mass
T
C
=25
°
C
1 cycle of half wave 60Hz, peak value, non-repetitive,
T
j
= 25
°
C start, V
RM
= 0V
Value of one cycle surge current,
t
W
= 8.3ms, T
j
= 25
°
C start
—
—
Charged part to base plate, rms, sinusoidal, AC 60Hz 1min.
Main terminals screw M8
Mounting screw M6
Typical value
600
4800
9.60
✕
10
4
–40 ~ +150
–40 ~ +125
6000
6.67 ~ 13.00
2.84 ~ 6.00
1.5
Symbol
Item
Conditions
Unit
Ratings
—
3.50
—
150
—
0.024
—
—
—
—
—
—
mA
V
µ
s
µ
C
K/W
K/W
Repetitive reverse current
Forward voltage
Reverse recovery time
Reverse recovery charge
Termal resistance
Contact thermal resistance
I
RRM
V
FM
t
rr
Q
rr
R
th(j-c)
R
th(c-f)
V
RRM
applied, V
RM
= V
RRM
I
FM
= 600A
I
FM
= 600A, d
if
/d
t
= –1200A/
µ
s,
V
R
= 1650V
Junction to case (Per 1/2 module)
Case to fin, conductive grease applied (Per 1/2 module)
Min
Typ
Max
Symbol
Item
Test conditions
Limits
Unit
ELECTRICAL CHARACTERISTICS
(Tj = 25
°
C)
4
4.55
1.20
—
0.048
—
66
3300
3300
2200
HVDi (High Voltage Diode) Module
