ST300CPbF Series
Vishay High Power Products Phase Control Thyristors
(Hockey PUK Version), 650 A
Fig. 1 - Current Ratings Characteristics
Fig. 2 - Current Ratings Characteristics
Fig. 3 - Current Ratings Characteristics
Fig. 4 - Current Ratings Characteristics
Fig. 5 - On-State Power Loss Characteristics
Fig. 6 - On-State Power Loss Characteristics
Average On-state Current (A)
Maximum Allowable Heatsink Temperature (°C)
30
40
50
60
70
80
90
100
110
120
130
0 100 200 300 400 500
30°
60°
90°
120°
180°
Conduction Angle
ST300C..C Series
(Single Side Cooled)
R (DC) = 0.09 K/W
thJ-hs
Average On-state Current (A)
Maximum Allowable Heatsink Temperature (°C)
20
30
40
50
60
70
80
90
100
110
120
130
0 200 400 600 800
DC
30°
60° 90°
120°
180°
Conduction Period
ST300C..C Series
(Single Side Cooled)
R (DC) = 0.09 K/W
thJ-hs
Average On-state Current (A)
Maximum Allowable Heatsink Temperature (°C)
10
20
30
40
50
60
70
80
90
100
110
120
130
0 200 400 600 800 1000
30°
60°
90°
120°
180°
Conduction Angle
ST300C..C Series
(Double Side Cooled)
R (DC) = 0.04 K/W
thJ-hs
Average On-state Current (A)
Maximum Allowable Heatsink Temperature (°C)
20
30
40
50
60
70
80
90
100
110
120
130
0 200 400 600 800 1000 1200 1400
DC
30°
60°
90°
120°
180°
Conduction Period
ST300C..C Series
(Double Side Cooled)
R (DC) = 0.04 K/W
thJ-hs
Average On-state Current (A)
Maximum Average On-state Power Loss (W)
0
200
400
600
800
1000
1200
1400
1600
0 100 200 300 400 500 600 700
180°
120°
90°
60°
30°
RMS Limit
Conduction Angle
ST300C..C Series
T = 125 °C
J
Average On-state Current (A)
Maximum Average On-state Power Loss (W)
0
200
400
600
800
1000
1200
1400
1600
1800
0 200 400 600 800 1000 1200
DC
180°
120°
90°
60°
30°
RMS Limit
Conduction Period
ST300C..C Series
T = 125 °C
J
