Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Intellimod™ Module
Single Phase
IGBT Inverter Output
200 Amperes/1200 Volts
PM200DVA120
443
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
□
Complete Output Power
Circuit
□
Gate Drive Circuit
□
Protection Logic
– Short Circuit
– Over Temperature
– Under Voltage
Applications:
□
Inverters
□
UPS
□
Motion/Servo Control
□
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM200DVA120 is a 1200V,
200 Ampere Intellimod™ Intelligent
Power Module.
Type
Current Rating
V
CES
Amperes
Volts (x 10)
PM
200
120
Outline Drawing and Circuit Diagram
Dimensions
Inches
Millimeters
A
4.72
120.0
B
2.76
70.0
C
1.14 +0.04/-0.02 29.0 +1.0/-0.5
D
4.17
±
0.010
106.0
±
0.25
E
2.20
±
0.010
56.0
±
0.25
F
1.52
38.5
G
0.16
4.0
H
0.16
4.01
J
0.40
10.16
K
0.55
14.0
L
1.02
26.0
M
0.45
11.5
Dimensions
Inches
Millimeters
N
0.12
3.0
P
1.50
38.0
Q
0.98
25.0
R
0.37
9.3
S
M6 Metric
M6
T
0.26 Dia.
Dia. 6.5
U
0.72
18.3
V
0.10
2.54
W
0.025 SQ
0.64 SQ
X
0.14 Dia.
3.5 Dia.
Y
1.10
28.0
SINK
SENS
OUT 2
OUT 1
TEMP
GND
V
CC
F
O
TH
E2
C2E1
C1
RG
IN
CI
V
NC
C
N1
S
NR
F
NO
V
N1
V
PC
C
P1
F
PO
S
PR
V
P1
SR
RREF
RFO
AMP
SINK
SENS
OUT 2
OUT 1
TEMP
GND
V
CC
F
O
RG
IN
CI
SR
RFO
AMP
TERMINAL CODE
1. V
N1
2. S
NR
3. C
N1
4. V
NC
5. F
NO
1. V
P1
2. S
PR
3. C
P1
4. V
PC
5. F
PO
C
D
U
A
B
R
E
Q
Q
P
N
G
S NUTS - 3 TYP.
F
H
J
V
L
M
K
K
K
T - 4 TYP.
W SQ. PIN
(10 PLACES)
XØ (2 PLACES)
Y
