Vitreous Wirewound Resistors with Lugs
GWS
Vishay Draloric
www.vishay.com
For technical questions contact [email protected]
Document Number: 21003
78
Revision: 28-Aug-06
FEATURES
• Complete welded construction
• Ceramic core
• High quality vitreous coating
• Available in adjustable or non-inductive design
• Lugs with various termination styles suitable for soldering
or bolt connection
• TCR 100. . .180 ppm/K
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
TERMINAL
SIZE
DIN 41432
POWER RATING
P
40 °C
W
LIMITING
VOLTAGE
V
RESISTANCE
RANGE
Ω
TOLERANCE
± %
E-SERIES
GWS 15
SL
9 x 45
15
250
4R3 - 20K
10
E 12
E 24
DIN 41432
4R3 - 20K
5
30R - 15K
3
220R - 20K
2
GWS 15 E
9 x 45
10
250
4R3 - 620R
10
E 12
4R3 - 620R
5
E 24
GWS 15 Ni
9 x 45
10
250
5R1 - 910R
10
E 12
5R1 - 910R
5
E 24
GWS 20
SL SS
-
20
300
3R6 - 30K
10
E 12
E 24
3R6 - 30K
5
-
3
180R - 30K
2
GWS 20 E
-
15
300
4R3 - 1K0
10
E 12
4R3 - 1K0
5
E 24
GWS 20 Ni
-
15
300
5R1 - 1K3
10
E 12
5R1 - 1K3
5
E 24
GWS 25
SL SS
13 x 55
25
300
3R6 - 39K
10
E 12
E 24
DIN 41432
3R6 - 39K
5
30R - 20K
3
91R - 39K
2
GWS 25 E
13 x 55
18
300
5R1 - 1K3
10
E 12
5R1 - 1K3
5
E 24
GWS 25 Ni
13 x 55
18
300
6R8 - 1K8
10
E 12
6R8 - 1K8
5
E 24
GWS 35
SL SS
-
30
400
5R1 - 47K
10
E 12
E 24
5R1 - 47K
5
-
3
56R - 47K
2
GWS 35 E
-
22
400
6R8 - 1K6
10
E 12
6R8 - 1K6
5
E 24
GWS 35 Ni
-
22
400
8R2 - 2K4
10
E 12
8R2 - 2K4
5
E 24
GWS 50
SL SS SB FST
16 x 63
40
400
3R3 - 62K
10
E 12
E 24
DIN 41432
3R3 - 62K
5
33R - 24K
3
100R - 62K
2
GWS 50 E
16 x 63
30
400
8R2 - 2K0
10
E 12
8R2 - 2K0
5
E 24
GWS 50 Ni
16 x 63
30
400
10R - 3K0
10
E 12
10R - 3K0
10
E 24
GWS 75
SL SS SB FST
16 x 100
65
800
7R5 - 130K
10
E 12
E 24
DIN 41432
7R5 - 130K
5
15R - 39K
3
30R - 130K
2
GWS 75 E
16 x 100
45
800
18R - 3K9
10
E 12
18R - 3K9
5
E 24
GWS 75 Ni
16 x 100
45
800
22R - 6K2
10
E 12
22R - 6K2
5
E 24
GWS 100
SS SSB SB
FST
24 x 100
80
600
6R8 - 110K
10
E 12
E 24
DIN 41432
6R8 - 110K
5
20R - 51K
3
75R - 110K
2
GWS 100 E
24 x 100
60
600
13R - 5K1
10
E 12
13R - 5K1
5
E 24
GWS 100 Ni
24 x 100
60
600
24R - 6K8
10
E 12
24R - 6K8
5
E 24
