PM150CSA060
Intellimod™ Module
Three Phase IGBT Inverter Output
150 Amperes/600 Volts
490
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
IGBT Inverter Sector
Collector Cutoff Current I
CEX
V
CE
= V
CEX
, T
j
= 25 ° C — — 1.0 mA
V
CE
= V
CEX
, T
j
= 125 ° C — — 10 mA
Diode Forward Voltage V
FM
-I
C
= 150A, V
D
= 15V, V
CIN
= 15V — 2.2 3.3 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
V
D
= 15V, V
CIN
= 0V, I
C
= 150A — 1.8 2.7 Volts
V D = 15V, V CIN = 0V, I C = 150A, — 1.75 2.63 Volts
T j = 125
°
C
Inductive Load Switching Times t
on
0.4 0.8 2.0 µ S
t
rr
V
D
= 15V, V
CIN
= 0 ~ 15V — 0.15 0.3
µ
S
t
C(on)
V
CC
= 300V, I
C
= 150A — 0.4 1.0
µ
S
t
off
T
j
= 125
°
C (Fig. 4, Fig. 5) — 2.0 2.9
µ
S
t C(off) — 0.6 1.2
µ
S
Thermal Characteristics
Characteristic Symbol Condition Min. Typ. Max. Units
Junction to Case Thermal Resistance R
th(j-c)Q
Each IGBT — — 0.25 ° C/Watt
R
th(j-c)D
Each FWDi — — 0.47 ° C/Watt
Contact Thermal Resistance R
th(c-f)
Case to Fin Per Module, — — 0.027
°
C/Watt
Thermal Grease Applied
Recommended Conditions for Use
Characteristic Symbol Condition Value Units
Supply Voltage V
CC
Applied across P-N Terminals 0 ~ 400 Volts
V
D
Applied between V
UP1
-V
UPC
, 15 ± 1.5 Volts
V
N1
-V
NC
, V
VP1
-V
VPC
, V
WP1
-V
WPC
Input ON Voltage V
CIN(on)
Applied between 0 ~ 0.8 Volts
Input OFF Voltage V CIN(off) U P , V P , W P , U N, V N, W N 4.0 ~ V D Volts
PWM Input Frequency f
PWM
Using Application Circuit 5 ~ 20 kHz
Minimum Dead Time t
DEAD
Input Signal ≥ 2.5 µ S
