Intellimod™ L1-Series
Three Phase
IGBT Inverter + Brake
75 Amperes/600 Volts
PM75RL1A060
1
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
www.pwrx.com
03/10 Rev. 1
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
£
Complete Output Power
Circuit
£
Gate Drive Circuit
£ Protection Logic
– Short Circuit
– Over Temperature
Using On-chip
Temperature Sensing
– Under Voltage
£
Low Loss Using Full Gate
CSTBT ™ IGBT Chip
Applications:
£
Inverters
£ UPS
£ Motion/Servo Control
£ Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM75RL1A060 is a 600V,
75 Ampere Intellimod™ Intelligent
Power Module.
Type Current Rating V
CES
Amperes Volts (x 10)
PM 75 60
V CC
S
I
GND
GND
OUT
F O IN
OT
V CC
S
I
GND
GND
OUT
F O IN
OT
V CC
S
I
GND
GND
OUT
F O IN
OT
V CC
S
I
GND
GND
OUT
F O IN
OT
P U
Br
V W N B
V CC
S
I
GND
GND
OUT
F O IN
OT
V CC
S
I
GND
GND
OUT
F O IN
OT
V CC
S
I
GND
GND
OUT
F O IN
OT
UN FO VNC WN VN1 VN
VWPC
WP
WFO
VWP1
VVPC
VP
VFO
VVP1
VUPC
UP
UFO
VUP1
1.5k 1.5k 1.5k 1.5k
AD
AE
Z
T
AA
C
X
N
P
B U V W
1 5 9 19
19 F O
17 V N
14 V N1
11 W P
8 V VP1
2 U FO
6 V FO
5 V VPC
3 U P
7 V P
9 V WPC
10 W FO
12 V WP1
1 V UPC
4 V UP1
16 U N
15 Br
18 W N
13 V NC
TERMINAL
CODE
Q
R
V
Y
Y
L
W
P A
D E
G F
H J J J
K
K
K
K
U
L
U U
S
N
M
B
AB
(6 PLACES)
AC
(2 PLACES)
AF
AG
(2 PLACES)
F
Outline Drawing and Circuit Diagram
Dimensions
Inches Millimeters
A 4.72 120.0
B 2.17 55.0
C 0.63 16.0
D 4.17 106.0
E 0.28 7.0
F 0.78 19.75
G 2.62 66.5
H 0.13 3.25
J 0.63 16.0
K 0.08 2.0
L 0.47 12.0
M 1.08 27.5
N 0.57 13.5
P 0.43 11.0
Q 0.42 10.75
R 1.29 32.75
Dimensions Inches Millimeters
S 0.46 11.75
T 0.86+0.04/0.02 22.0+1.0/-0.5
U 0.91 23.0
V 0.57 14.5
W 1.26 32.0
X 1.24 31.5
Y 0.69 17.5
Z Screw Depth 12
AA 0.51 13.0
AB M5 Metric M5
AC 0.22 Dia. 5.5 Dia.
AD 0.28 7.0
AE 0.12 3.0
AF 0.02 Sq. 0.5 Sq.
AG 0.10 Dia. 2.5 Dia.
