3
PM50RSD120
Intellimod™ Module
Three Phase + Brake IGBT Inverter Output
50 Amperes/1200 Volts
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
IGBT Inverter Sector
Collector Cutoff Current I
CES
V
CE
= V
CES
, T
j
= 25
°
C, V
D
= 15V — — 1.0 mA
V
CE
= V
CES
, T
j
= 125
°
C, V
D
= 15V — — 10 mA
Diode Forward Voltage V
EC
-I
C
= 50A, V
D
= 15V, V
CIN
= 15V — 2.5 3.5 Volts
Collector-Emitter Saturation Voltage V CE(sat) V D = 15V, V CIN = 0V, I C = 50A, — 2.4 3.2 Volts
Pulsed, T
j
= 25 ° C
V
D
= 15V, V
CIN
= 0V, I
C
= 50A, — 2.1 2.8 Volts
Pulsed, T
j
= 125
°
C
Inductive Load Switching Times t
on
0.5 1.0 2.5 µ S
t
rr
V
D
= 15V, V
CIN
= 0 ~ 15V — 0.15 0.3
µ
S
t
C(on)
V
CC
= 600V, I
C
= 50A — 0.4 1.0
µ
S
t
off
T
j
= 125
°
C, Inductive Load — 2.5 3.5
µ
S
t C(off) — 0.7 1.2
µ
S
IGBT Brake Sector
Collector Cutoff Current I CES V CE = V CES , T j = 25
°
C, V D = 15V — — 1.0 mA
V
CE
= V
CES
, T
j
= 125 ° C, V
D
= 15V — — 10 mA
FWDi Forward Voltage V
FM
I
F
= 15A — 2.5 3.5 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
V
D
= 15V, V
CIN
= 0V, I
C
= 15A, — 2.5 3.3 Volts
Pulsed, T j = 25
°
C
V
D
= 15V, V
CIN
= 0V, I
C
= 15A, — 2.2 3.2 Volts
Pulsed, T
j
= 125 ° C
Control Sector
Over Current Trip Level Inverter Part OC T
j
= 25
°
C 93 157 — Amperes
(V D = 15V) T j = 125
°
C 59 — — Amperes
Over Current Trip Level Brake Part OC -20 ° C ≤ T
j
≤ 125 ° C, V
D
= 15V 22 — — Amperes
Short Circuit Trip Level Inverter Part SC -20 ° C ≤ T
j
≤ 125 ° C, V
D
= 15V — 183 — Amperes
Short Circuit Trip Level Brake Part — 95 — Amperes
Over Current Delay Time t
off(OC)
V
D
= 15V — 10 —
µ
S
Over Temperature Protection (V
D
= 15V) OT Trip Level 111 118 125
°
C
(Lower Arm) OT R Reset Level — 100 —
°
C
Supply Circuit Under Voltage Protection UV Trip Level 11.5 12.0 12.5 Volts
(-20 ≤ T
j
≤ 125 ° C) UV
R
Reset Level — 12.5 — Volts
Circuit Current I
D
V
D
= 15V, V
CIN
= 15V, V
N1
-V
NC
— 44 60 mA
V
D
= 15V, V
CIN
= 15V, V
XP1
-V
XPC
— 13 18 mA
Input ON Threshold Voltage V CIN(on) Applied between U P -V UPC , V P -V VPC , 1.2 1.5 1.8 Volts
Input OFF Threshold Voltage V CIN(off) W P -V WPC , U N , V N , W N , B r -V NC 1.7 2.0 2.3 Volts
Fault Output Current* I
FO(H)
V
D
= 15V, V
CIN
= 15V — — 0.01 mA
I
FO(L)
V
D
= 15V, V
CIN
= 15V — 10 15 mA
Minimum Fault Output Pulse Width* t
FO
V
D
= 15V 1.0 1.8 — mS
*Fault output is given only when the internal OC, SC, OT and UV protections schemes of either upper or lower arm device operate to protect it.
