Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
POW-R-BLOK
TM
www.pwrx.com
Single Diode Isolated Module
800 Amperes / Up to 5000 Volts
Revision Date: 07/19/2012
PS415008
®
Preliminary
Electrical Characteristics, T
J
=25
C unless otherwise specified
Characteristics
Symbol
Test Conditions
Min.
Max.
Units
Repetitive Peak Reverse Leakage Current
I
RRM
Up to 5000V, T
J
=150
C
600
mA
Peak On-State Voltage
V
FM
I
FM
=3000A, T
J
=150
C
2.40
V
Threshold Voltage, Low-level
Slope Resistance, Low-level
V
(TO)1
r
T1
T
J
= 150
C, I = 15%I
T(AV)
to πI
T(AV)
0.950
0.430
V
mΩ
Threshold Voltage, High-level
Slope Resistance, High-level
V
(TO)2
r
T2
T
J
= 150
C, I = πI
T(AV)
to I
TSM
1.098
0.380
V
mΩ
V
FM
Coefficients, Full Range
T
J
= 150
C, I = 50A to 10kA
V
FM
= A+ B Ln I +C I + D Sqrt I
A =
B =
C =
D =
0.87766
0.01004
3.67 E-04
2.40 E-03
Typical Reverse Recovery Time
trr
T
J
= 25
C, I
fm
= 1500A.
dI
r
/dt = 25 A/us, t
p
= 190 us
30
us
Thermal Characteristics
Characteristics
Symbol
Max.
Units
Thermal Resistance, Junction to Case
RΘ
J-C
Per Module
0.043
C/W
Thermal Impedance Coefficients
ZΘ
J-C
ZΘ
J-C
= K
1
(1-exp(-t/
1
))
+ K
2
(1-exp(-t/
2
))
+ K
3
(1-exp(-t/
3
))
+ K
4
(1-exp(-t/
4
))
K
1
= 1.85 E-04
K
2
= 1.40 E-03
K
3
= 2.90 E-03
K
4
=3.90 E-02
1
= 1.53 E-03
2
= 4.52 E-02
3
= 1.32
4
= 19.17
Thermal Resistance, Case to Sink Lubricated
RΘ
C-S
Per Module
0.009
C/W
