PM100RSA060
Intellimod™ Module
Three Phase + Brake IGBT Inverter Output
100 Amperes/600 Volts
566
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
IGBT Inverter Sector
Collector Cutoff Current I
CES
V
CE
= V
CES
, T
j
= 25 ° C — — 1.0 mA
V
CE
= V
CES
, T
j
= 125 ° C — — 10 mA
Diode Forward Voltage V
FM
-I
C
= 100A, V
D
= 15V, V
CIN
= 5V — 2.2 3.3 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
V
D
= 15V, I
CIN
= 0V, I
C
= 100A — 1.8 2.7 Volts
V D = 15V, V CIN = 0V, I C = 100A, — 1.75 2.63 Volts
T j = 125
°
C
Inductive Load Switching Times t
on
0.4 0.8 2.0 µ S
t
rr
V
D
= 15V, V
CIN
= 0 ~15V — 0.15 0.3
µ
S
t
C(on)
V
CC
= 300V, I
C
= 100A — 0.4 1.0
µ
S
t
off
T
j
= 125
°
C — 2.0 2.9
µ
S
t C(off) — 0.6 1.2
µ
S
Brake Sector
Collector-Emitter Saturation Voltage V CE(sat) V D = 15V, V CIN = 0V, I C = 100A, — 2.7 3.5 Volts
T
j
= 25 ° C
V
D
= 15V, V
CIN
= 0V, I
C
= 100A, — 3.1 4.0 Volts
T
j
= 125 ° C
Diode Forward Voltage V
FM
-I
C
= 30A, V
D
= 15V, V
CIN
= 5V — 1.7 2.7 Volts
Collector Cutoff Current I
CES
V
CE
= V
CES
, T
j
= 25
°
C — — 1 mA
V CE = V CES , T j = 125
°
C — — 10 mA
