Page 2
www.vishay.com
13
Phawo...k..
Vishay ESTA
Document Number: 13056
Revision 28-Mar-02
TYPE DESIGNATION
Ph
a
w o s 750 /
1875 / 1k -
.
.
.
monitoring device *)
frequency (kHz)
total output (kVAr)
voltage (V or kV)
live casing (grounded casing: no entry Phawo 750/...
NON-PCB
water-cooled
all fi lm dielectric
power capacitor
*) – ST = thermostat
– DR = pressure switch
Medium Frequency Capacitors, Water Cooled
ESTAfi lm
®
, SINGLE OUTPUTS NOT SUBDIVIDED, 150 - 5000Hz
DESIGN
• All-fi lm winding in brass sheet welded casing;
• Casing conductive, or grounded;
• Casing varnish RAL 7033;
• IP00, indoor;
• Ambient temperature 1°C .... 50°C;
• Outfl owing water temperature 40° C maximum;
• 2 water-cooled current connections M20;
• Water tubing conductive;
• Mounting in the upright or horizontal position;
• Upon request, temperature or pressure monitoring;
α
) water connection
158
50
44
70
44
82.5
11 x 15
429
407
5
rating plate
2 x ø 9.8
H1
165
x) thermostat
x) upon request
α
)
α
)
H
369
}
Not all types available.
