Vishay high power products, Fast recovery diodes (hockey puk version), 990 a – C&H Technology SD853C..S50K Series User Manual
Page 3

Document Number: 93182
For technical questions, contact: [email protected]
www.vishay.com
Revision: 14-May-08
3
SD853C..S50K Series
Fast Recovery Diodes
(Hockey PUK Version), 990 A
Vishay High Power Products
Note
• The table above shows the increment of thermal resistance R
thJ-hs
when devices operate at different conduction angles than DC
THERMAL AND MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL
TEST
CONDITIONS
VALUES
UNITS
Maximum junction operating
temperature range
T
J
- 40 to 125
°C
Maximum storage temperature range
T
Stg
- 40 to 150
Maximum thermal resistance,
junction to heatsink
R
thJ-hs
DC operation single side cooled
0.04
K/W
DC operation double side cooled
0.02
Mounting force, ± 10 %
22 250 (2250)
N (kg)
Approximate weight
425
g
Case style
See dimensions - link at the end of datasheet
DO-200AC (K-PUK)
ΔR
thJ-hs
CONDUCTION
CONDUCTION ANGLE
SINUSOIDAL CONDUCTION
RECTANGULAR CONDUCTION
TEST CONDITIONS
UNITS
SINGLE SIDE
DOUBLE SIDE
SINGLE SIDE
DOUBLE SIDE
180°
0.0017
0.0019
0.0012
0.0012
T
J
= T
J
maximum
K/W
120°
0.0021
0.0021
0.0021
0.0021
90°
0.0026
0.0027
0.0029
0.0029
60°
0.039
0.0039
0.0041
0.0041
30°
0.0067
0.0067
0.0068
0.0068
