VSKU91.., VSKV91.. Series
ADD-A-PAK Generation VII Power Modules
Thyristor/Thyristor, 95 A
Vishay High Power Products
Note
• Table shows the increment of thermal resistance R
thJC
when devices operate at different conduction angles than DC
TRIGGERING
PARAMETER
SYMBOL
TEST CONDITIONS
VALUES
UNITS
Maximum peak gate power
P
GM
12
W
Maximum average gate power
P
G(AV)
3.0
Maximum peak gate current
I
GM
3.0
A
Maximum peak negative gate voltage
- V
GM
10
V
Maximum gate voltage required to trigger
V
GT
T
J
= - 40 °C
Anode supply = 6 V
resistive load
4.0
T
J
= 25 °C
2.5
T
J
= 125 °C
1.7
Maximum gate current required to trigger
I
GT
T
J
= - 40 °C
Anode supply = 6 V
resistive load
270
mA
T
J
= 25 °C
150
T
J
= 125 °C
80
Maximum gate voltage that will not trigger
V
GD
T
J
= 125 °C, rated V
DRM
applied
0.25
V
Maximum gate current that will not trigger
I
GD
T
J
= 125 °C, rated V
DRM
applied
6
mA
BLOCKING
PARAMETER
SYMBOL
TEST CONDITIONS
VALUES
UNITS
Maximum peak reverse and off-state
leakage current at V
RRM
, V
DRM
I
RRM,
I
DRM
T
J
= 125 °C, gate open circuit
15
mA
RMS insulation voltage
V
INS
50 Hz, 1 s
3500
V
Maximum critical rate of rise of off-state voltage
dV/dt
T
J
= 125 °C, linear to 0.67 V
DRM
1000
V/µs
THERMAL AND MECHANICAL SPECIFICATIONS
PARAMETER
SYMBOL
TEST CONDITIONS
VALUES
UNITS
Junction operating and storage
temperature range
T
J
, T
Stg
- 40 to 125
°C
Maximum internal thermal resistance,
junction to case per leg
R
thJC
DC operation
0.22
°C/W
Typical thermal resistance,
case to heatsink per module
R
thCS
Mounting surface flat, smooth and greased
0.1
Mounting torque ± 10 %
to heatsink
A mounting compound is recommended and the
torque should be rechecked after a period of
3 hours to allow for the spread of the compound.
4
Nm
busbar
3
Approximate weight
75
g
2.7
oz.
Case style
JEDEC
TO-240AA compatible
ΔR CONDUCTION PER JUNCTION
DEVICES
SINE HALF WAVE CONDUCTION
RECTANGULAR WAVE CONDUCTION
UNITS
180°
120°
90°
60°
30°
180°
120°
90°
60°
30°
VSK.91..
0.04
0.048
0.063
0.085
0.125
0.033
0.052
0.067
0.088
0.127
°C/W
