UFB120FA40P
Vishay High Power Products Insulated Ultrafast
Rectifier Module, 120 A
ELECTRICAL SPECIFICATIONS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Cathode to anode breakdown voltage V
BR
I
R
= 100 µA 400 - -
V
Forward voltage V
FM
I
F
= 60 A - 1.16 1.37
I
F
= 60 A, T
J
= 150 °C - 0.96 1.13
Reverse leakage current I
RM
V
R
= V
R
rated - - 0.1
mA
T
J
= 150 °C, V
R
= V
R
rated - - 1
Junction capacitance C
T
V
R
= 400 V - 67 - pF
DYNAMIC RECOVERY CHARACTERISTICS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
I
F
= 1.0 A, dI
F
/dt = 200 A/µs, V
R
= 30 V - 30 35
ns T
J
= 25 °C
I
F
= 50 A
dI
F
/dt = 200 A/µs
V
R
= 200 V
- 65 -
T
J
= 125 °C - 128 -
Peak recovery current I
RRM
T
J
= 25 °C - 7.4 -
A
T
J
= 125 °C - 17.8 -
Reverse recovery charge Q
rr
T
J
= 25 °C - 240 -
nC
T
J
= 125 °C - 1139 -
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Junction to case, single diode conducting
R
thJC
- 0.99 1.24
°C/W Junction to case, both diodes conducting - 0.49 0.62
Case to heatsink R
thCS
Flat, greased surface - 0.05 -
Weight - 30 - g
Mounting torque - 1.3 - Nm
