Document Number: 52014

For technical questions, contact: [email protected]

www.vishay.com

Revision: 10-Jun-08

High Ohmic Values (up to 100 G

Ω), High Voltage Resistors (up to 50 kV)

Thick Film Technology

HTS

Vishay Sfernice

FEATURES

• RoHS for most values, please consult us
• Core: High purity ceramic
• Coating: Epoxy
• Termination: Standard lead material is solder

coated copper

• Climatic category: - 55 °C/+ 155 °C/56 days
• High ohmic values: Up to 100 GΩ
• High voltage application: Up to 50 kV

DIMENSIONS in millimeters

MARKING

GEKA trade-mark, series, style, nominal resistance (in

Ω), tolerance (in %), letter P for TCR ± 150 ppm/°C, manufacturing date.

Because of lack of space, small styles are marked with ohmic value (in

Ω), tolerance (in %) and letter P.

RoHS

COMPLIANT

STYLE

DIM.

523

547

729

747

923

932

947

972

9100

7 ± 0.2 8.5 ± 0.5

14 ± 1

23 ± 2

47 ± 2

29 ± 2

47 ± 2

23 ± 2

32 ± 2

47 ± 2

72 ± 2

100 ± 2

Ø B

1.6 ± 0.2 2.2 ± 0.2 3.5 ± 0.3 4.5 ± 0.3 4.5 ± 0.3 6.5 ± 0.5 6.5 ± 0.5

8.5 ± 0.5

Ø E ± 0.1

0.6

0.8

Weight in g

0.24

0.29

0.67

1.23

4.60

5.27

7.18

TECHNICAL SPECIFICATIONS

SERIES AND STYLES

HTS

523

HTS

547

HTS

729

HTS

747

HTS

923

HTS

932

HTS

947

HTS

972

HTS

9100

Power Rating at + 70 °C

0.25 W

0.5 W

1 W

1.5 W

2 W

2.5 W

2 W

2.5 W

3 W

4 W

5 W

Ohm

ic Range

Relation

• T

efficient

50 pp

m/°

• T

lerance

± 0.5 %

200

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

1 k

100 M

± 1 %

1 k

250 M

1 k

500 M

1 k

500 M

1 k

1 G

1 k

1 G

1 k

1 G

1 k

1 G

1 k

1 G

1 k

1 G

1 k

1 G

1 k

1 G

± 2 %

1 k

200 M

1 k

500 M

1 k

2.5 G

1 k

5 G

1 k

10 G

1 k

10 G

1 k

10 G

1 k

10 G

1 k

10 G

1 k

10 G

1 k

10 G

1 k

10 G

± 5 %

± 10 %

1 k

50 G

1 k

15 G

1 k

30 G

1 k

15 G

1 k

30 G

1 k

50 G

1 k

100 G

1 k

100 G

Limiting Element Voltage

0.5 kV

1 kV

2 kV

5 kV

15 kV

10 kV

15 kV

8 kV

15 kV

20 kV

30 kV

50 kV

Critical Resistance

1 M

2 M

4 M

25 M

150 M

50 M

90 M

32 M

90 M

133.3 M

Ω 225 MΩ

500 M

ORDERING INFORMATION

HTS

1M27

0.5 %

150 ppm/°C

AM500

MODEL

SIZE

OHMIC VALUE

TOLERANCE

TEMPERATURE

COEFFICIENT

P: Standard: ± 150 ppm/°C

PACKAGING

LEAD (Pb)-FREE

25 min.

Ø B

Ø E

L max.

° chamfer

max. 0.25 mm deep

Ø a ± 0.02
