5
PM300RSD060
Intellimod™ Module
Three Phase + Brake IGBT Inverter Output
300 Amperes/600 Volts
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Thermal Characteristics
Characteristic Symbol Condition Min. Typ. Max. Units
Junction to Case Thermal Resistance R
th(j-c)Q
Each IGBT — — 0.16 ° C/Watt
Inverter Part R
th(j-c)F
Each FWDi — — 0.24 ° C/Watt
R
th(j-c´)Q
Each IGBT* — — 0.10** ° C/Watt
R th(j-c´)F Each FWDi* — — 0.16** ° C/Watt
Junction to Case Thermal Resistance R
th(j-c)Q
Each IGBT — — 0.30 ° C/Watt
Brake Part R
th(j-c)F
Each FWDi — — 0.80 ° C/Watt
R
th(j-c´)Q
Each IGBT* — — 0.22** ° C/Watt
R
th(j-c´)F
Each FWDi* — — 0.36** ° C/Watt
Contact Thermal Resistance R th(c-f) Case to Fin Per Module, — — 0.018 ° C/Watt
Thermal Grease Applied
*T C measured point is just under chip.
**If you use this value, R th(f-a) should be measured just under the chips.
Recommended Conditions for Use
Characteristic Symbol Condition Value Units
Supply Voltage V CC Applied across P-N Terminals 0 ~ 400 Volts
Control Supply Voltage*** V
D
Applied between V
UP1
-V
UPC
, 15 ± 1.5 Volts
V
N1
-V
NC
, V
VP1
-V
VPC
, V
WP1
-V
WPC
Input ON Voltage V
CIN(on)
Applied between 0 ~ 0.8 Volts
Input OFF Voltage V
CIN(off)
U
P
, V
P
, W
P
, U
N,
V
N,
W
N,
B
r
-V
NC
4.0 ~ V
D
Volts
PWM Input Frequency f
PWM
Using Application Circuit 0 ~ 20 kHz
Minimum Dead Time t DEAD Input Signal ≥ 2.0 µ S
I
F
= 12mA ≥ 2.5 µ S
*** With ripple satisfying the following conditions: dv/dt swing ≤ ± 5V/ µ s, Variation ≤ 2V peak to peak.
