HFA90NH40PbF
Vishay High Power Products HEXFRED ®
Ultrafast Soft Recovery Diode, 210 A
Fig. 12 - Avalanche Test Circuit and Waveforms
ORDERING INFORMATION TABLE
V
(AVAL)
V
R(RATED)
I
L(PK)
Decay
time
Current
monitor
High-speed
switch
D.U.T.
R
g
= 25 Ω
+
Freewheel
diode
V
d
= 50 V
L = 100 µH
1 - HEXFRED ® family
2 - Average current rating
3 - N = Not isolated
4 - H = HALF-PAK
5 - Voltage rating (400 V)
6 - Lead (Pb)-free
Device code
5 1 3 2 4 6
HFA 90 N H 40 PbF
LINKS TO RELATED DOCUMENTS
Dimensions http://www.vishay.com/doc?95020
