www.vishay.com For technical questions, contact: [email protected] Document Number: 94520
2 Revision: 07-May-08
UFB60FA20P
Vishay High Power Products Insulated Ultrafast
Rectifier Module, 60 A
ELECTRICAL SPECIFICATIONS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Cathode to anode breakdown voltage V
BR
I
R
= 100 µA 200 - -
V
Forward voltage V
FM
I
F
= 30 A - 0.96 1.08
I
F
= 30 A, T
J
= 150 °C - 0.78 0.86
Reverse leakage current I
RM
V
R
= V
R
rated - - 100 µA
T
J
= 150 °C, V
R
= V
R
rated - - 1.0 mA
Junction capacitance C
T
V
R
= 200 V - 119 - pF
DYNAMIC RECOVERY CHARACTERISTICS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
I
F
= 1.0 A, dI
F
/dt = 200 A/µs, V
R
= 30 V - - 27
ns T
J
= 25 °C
I
F
= 30 A
dI
F
/dt = 200 A/µs
V
R
= 100 V
- 31 -
T
J
= 125 °C - 51 -
Peak recovery current I
RRM
T
J
= 25 °C - 2.7 -
A
T
J
= 125 °C - 6.8 -
Reverse recovery charge Q
rr
T
J
= 25 °C - 41 -
nC
T
J
= 125 °C - 174 -
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Junction to case,
single leg conducting
R
thJC
- - 1.9 °C/W
Junction to case,
both leg conducting
- - 0.95
K/W
Case to heatsink R
thCS
Flat, greased surface - 0.05 -
Weight - 30 - g
Mounting torque - 1.3 - Nm
