ET
Vishay ESTA
Document Number: 13014
Revision 04-Jan-02 www.vishay.com
5
PART DIMENSIONS
NUMBER µF L mm D mm
25KVDC WKG
ET250-501 0.0005* 145 17
ET250-102 0.001* 145 20
ET250-502 0.005 175 30
ET250-103 0.01 175 35
ET250-503 0.05 300 42
30KkVDC WKG
ET300-501 0.0005* 170 17
ET300-102 0.001* 170 20
ET300-202 0.002 170 25
ET300-502 0.005 205 30
ET300-103 0.01 205 35
ET300-203 0.02 280 35
ET300-303 0.03 280 42
40KVDC WKG
ET400-102 0.001* 210 20
ET400-202 0.002 275 20
ET400-103 0.01 275 42
50KVDC WKG
ET500-501 0.0005* 275 22
ET500-102 0.001* 275 22
ET500-202 0.002 340 22
ET500-502 0.005 340 35
ET500-103 0.01 340 42
60KVDC WKG
ET600-102 0.001* 330 25
ET600-152 0.0015 330 30
PART DIMENSIONS
NUMBER µF L mm D mm
6000VDC WKG
ET60-102 0.001* 55 17
ET60-202 0.002* 55 17
ET60-502 0.005* 65 17
ET60-103 0.01 65 20
ET60-203 0.02 80 20
ET60-503 0.05 100 25
ET60-104 0.1 100 35
ET60-254 0.25 135 42
8000VDC WKG
ET80-502 0.005* 65 20
ET80-103 0.01 80 20
ET80-503 0.05 105 35
ET80-104 0.1 105 42
ET80-254 0.25 170 42
10KVDC WKG
ET100-102 0.001* 65 17
ET100-502 0.005* 65 22
ET100-103 0.01 80 22
ET100-203 0.02 80 30
ET100-503 0.05 105 35
ET100-104 0.1 170 35
ET100-254 0.25 205 42
12KVDC WKG
ET120-202 0.002* 95 20
ET120-502 0.005* 95 30
ET120-103 0.01 115 30
ET120-203 0.02 115 35
ET120-503 0.05 180 35
ET120-104 0.1 180 42
15KVDC WKG
ET150-102 0.001* 95 17
ET150-202 0.002* 95 20
ET150-502 0.005* 110 20
ET150-103 0.01 110 30
ET150-203 0.02 110 35
ET150-503 0.05 150 42
ET150-104 0.1 245 42
20KVDC WKG
ET200-102 0.001* 115 22
ET200-502 0.005* 145 25
ET200-103 0.01 145 30
ET200-203 0.02 195 30
ET200-503 0.05 245 42
ET200-104 0.1 320 42
DC Filter Capacitors
NOTE: Non standard size containers can be supplied on request.
