PM50B4L1C060
Photo Voltaic IPM
H-Bridge
50 Amperes/600 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272 www.pwrx.com
4
03/11 Rev. 0
Thermal Characteristics,
T
j
= 25°C unless otherwise specified
Characteristic
Symbol
Condition
Min.
Typ.
Max.
Units
Junction to Case Thermal Resistance
R
th(j-c)Q
Inverter IGBT (Per 1 Element)*
1
—
—
0.74 °C/Watt
R
th(j-c)D
Inverter FWDi (Per 1 Element)*
1
—
—
1.28 °C/Watt
Contact Thermal Resistance
R
th(c-f)
Case to Fin (Per 1 Element)*
1
, — 0.060 —
°C/Watt
Thermal Grease Applied
Recommended Conditions for Use
Characteristic
Symbol
Condition
Value Units
Inverter Supply Voltage
V
CC
Applied across P-N Terminals
≤450
Volts
Control Supply Voltage*
3
V
D
Applied between V
UP1
-V
UPC
,
15.0 ± 1.5 Volts
V
VP1
-V
VPC
, V
N1
-V
NC
Input ON Voltage
V
CIN(on)
Applied between U
P
-V
UPC
,
≤0.8
Volts
Input OFF Voltage
V
CIN(off)
V
P
-V
VPC
, U
N
- V
N
- W
N
-Br-V
NC
≥9.0 Volts
PWM Input Frequency
f
PWM
Using Application Circuit Input Signal of IPM,
≤20
kHz
3-Phase Sinusoidal PWM VVVF Inverter
Arm Shoot-through Blocking Time
t
DEAD
For IPMs Each Input Signals
≥2.0
µs
*1 When using this value, R
th(s-a)
should be measured just under the chips.
*3 With ripple satisfying the following conditions: dv/dt swing ≤5V/µs ; variation ≤2V peak-to-peak.
