Document Number: 95087 For technical questions concerning discrete products, contact: [email protected] www.vishay.com
Revision: 03-Aug-07 For technical questions concerning module products, contact: [email protected] 1
ADD-A-PAK Thyristor
Outline Dimensions
Vishay High Power Products
DIMENSIONS in millimeters (inches)
35 REF.
30 ± 0.5
(1.18 ± 0.0197)
29 ± 0.5
(1 ± 0.0197)
Viti M5 x 0.8
Screws M5 x 0.8
18 (0.7) REF.
15.6 ± 0.5
(0.6 ± 0.0197)
Faston tab 2.8 x 0.8 (0.110 x 0.03)
6.3 ± 0.3 (0.2 ± 0.0118)
30 ± 1 (1.18 ± 0.039)
24 ± 0.5
(1 ± 0.0197)
Detail Z
80 ± 0.3 (3.15 ± 0.0118)
92 ± 0.75 (3.6 ± 0.02953)
20 ± 0.5 (0.79 ± 0.0197)
20 ± 0.5 (0.79 ± 0.0197)
15 ± 0.5 (0.59 ± 0.0197)
21 ± 0.75
(0.8 ± 0.02953)
6.2 (2 x) ± 0.2 (0.2 ± 0.0079)
With no auxiliary cathode
1
2 3
45
76
13.8 REF.
5.8 ± 0.25
(0.2 ± 0.00984)
4 ± 0.2
(0.2 ± 0.0079)
45
76
13.8 (0.54)
46
