1
Trench Gate Design
Single IGBTMOD™
600 Amperes/1200 Volts
CM600HU-24F
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Outline Drawing and Circuit Diagram
Dimensions
Inches
Millimeters
A
4.33
110.0
B
3.15
80.0
C
1.34 +0.04/-0.02 34.0 +1.0/-0.5
D
3.66
±
0.01
93.0
±
0.25
E
2.44
±
0.01
62.0
±
0.25
F
0.22
5.5
G
0.57
14.5
H
0.53
13.5
J
0.96
24.5
Dimensions
Inches
Millimeters
K
1.14
29.0
L
0.37
9.5
N
1.02 +0.04/-0.02 26.0 +1.0/-0.5
P
0.85
21.5
Q
0.16
4.0
R
M8
M8
S
0.26 Dia.
6.5 Dia.
T
M4
M4
1
Description:
Powerex IGBTMOD™ Modules
are designed for use in switching
applications. Each module consists
of one IGBT Transistor in a single
configuration with a reverse-con-
nected super-fast recovery free-
wheel diode. All components and
interconnects are isolated from the
heat sinking baseplate, offering
simplified system assembly and
thermal management.
Features:
□
Low Drive Power
□
Low V
CE(sat)
□
Discrete Super-Fast Recovery
Free-Wheel Diode
□
Isolated Baseplate for Easy
Heat Sinking
Applications:
□
AC Motor Control
□
UPS
□
Battery Powered Supplies
Ordering Information:
Example: Select the complete
module number you desire from
the table - i.e. CM600HU-24F is a
1200V (V
CES
), 600 Ampere Dual
IGBTMOD™ Power Module.
Current Rating
V
CES
Type
Amperes
Volts (x 50)
CM
600
24
A
D
S (4 TYP)
CM
C
R (2 TYP.)
H
J
K
B
E
T (2 TYP)
G
N
E
G
E
C
Q
F
L
P
G
E
E
C
RTC
TC MEASURING
POINT
