VS-UFL80FA60
www.vishay.com
Vishay Semiconductors
Revision: 26-Oct-11
2
Document Number: 93643
For technical questions within your region:
,
,
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
ELECTRICAL SPECIFICATIONS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS MIN.
TYP.
MAX.
UNITS
Cathode to anode breakdown voltage
V
BR
I
R
= 100 μA
600
-
-
V
Forward voltage
V
FM
I
F
= 30 A
-
1.1
1.43
I
F
= 60 A
-
1.27
1.49
I
F
= 30 A
T
J
= 125 °C
-
1.0
1.23
I
F
= 60 A
-
1.17
1.35
Reverse leakage current
I
RM
V
R
= V
R
rated
-
0.1
50
μA
T
J
= 175 °C, V
R
= V
R
rated
-
0.2
1.0
mA
Junction capacitance
C
T
V
R
= 600 V
-
30
-
pF
DYNAMIC RECOVERY CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS MIN.
TYP.
MAX.
UNITS
Reverse recovery time
t
rr
T
J
= 25 °C
I
F
= 1 A;
dI
F
/dt = 200 A/μs;
V
R
= 30 V
-
41
-
ns
T
J
= 25 °C
I
F
= 30 A
dI
F
/dt = 200 A/μs
V
R
= 200 V
-
115
-
T
J
= 125 °C
-
200
-
Peak recovery current
I
RRM
T
J
= 25 °C
-
11
-
A
T
J
= 125 °C
-
20
-
Reverse recovery charge
Q
rr
T
J
= 25 °C
-
600
-
nC
T
J
= 125 °C
-
1900
-
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL
TEST
CONDITIONS
MIN. TYP. MAX.
UNITS
Junction to case, single leg conducting
R
thJC
-
-
1.02
°C/W
Junction to case, both leg conducting
-
-
0.51
Case to heatsink
R
thCS
Flat, greased surface
-
0.10
-
Weight
-
30
-
g
Mounting torque
-
1.3
-
Nm
Case style
SOT-227
