VS-175BGQ045
www.vishay.com
Vishay Semiconductors
Revision: 11-Dec-12
4
Document Number: 94582
For technical questions within your region:
,
,
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Fig. 7 - Maximum Non-Repetitive Surge Current
Fig. 8 - Unclamped Inductive Test Circuit
Note
(1)
Formula used: T
C
= T
J
- (Pd + Pd
REV
) x R
thJC
;
Pd = Forward power loss = I
F(AV)
x V
FM
at (I
F(AV)
/D) (see fig. 6);
Pd
REV
= Inverse power loss = V
R1
x I
R
(1 - D); I
R
at V
R1
= 80 % rated V
R
ORDERING INFORMATION TABLE
I
F
S
M
- Non-Repetitive
S
urge Current (A)
t
-
Square Wave Pulse Duration (μs)
1000
10 000
10 100 1000 10 000
At Any Rated Load Condition
And With Rated V
RRM
Applied
Following Surge
Current
monitor
High-speed
switch
D.U.T.
R
g
= 25
Ω
+
Freewheel
diode
V
d
= 25 V
L
IRFP460
40HFL40S02
2
-
Current rating
1
-
Vishay Semiconductors product
3
-
Essential part number
4
-
Voltage code = V
RRM
Device code
1
3
4
2
175
VS-
BGQ 045
LINKS TO RELATED DOCUMENTS
Dimensions
www.vishay.com/doc?95240
Part marking information
www.vishay.com/doc?95370
Application note
www.vishay.com/doc?95179
