C&H Technology PM75CVA120 User Manual
Page 4

427
PM75CVA120
Intellimod™ Module
Three Phase IGBT Inverter Output
75 Amperes/1200 Volts
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics,
T
j
= 25
°
C unless otherwise specified
Characteristics
Symbol
Test Conditions
Min.
Typ.
Max.
Units
Control Sector
Short Circuit Trip Level
SC
-20
°
C
≤
T
j
≤
125
°
C, V
D
= 15V
105
—
—
Amperes
Short Circuit Current Delay Time
t
off(SC)
V
D
= 15V
—
10
—
µ
S
Over Temperature Protection
OT
Trip Level
100
110
120
°
C
(V
D
= 15V, Lower Arm)
OT
r
Reset Level
85
95
105
°
C
Supply Circuit Under Voltage Protection
UV
Trip Level
11.5
12.0
12.5
Volts
(-20
°
C
≤
T
j
≤
125
°
C)
UV
r
Reset Level
—
12.5
—
Volts
Circuit Current
I
D
V
D
= 15V, V
CIN
= 15V, V
N1
-V
NC
—
40
55
mA
V
D
= 15V, V
CIN
= 15V, V
XP1
-V
XPC
—
13
18
mA
Input ON Threshold Voltage
V
CIN(on)
Applied between U
P
-V
UPC
, V
P
-V
VPC
,
1.2
1.5
1.8
Volts
Input OFF Threshold Voltage
V
CIN(off)
W
P
-V
WPC
, U
N
, V
N
, W
N
-V
NC
1.7
2.0
2.3
Volts
Fault Output Current
I
FO(H)
V
D
= 15V, V
FO
= 15V*
—
—
0.01
mA
I
FO(L)
V
D
= 15V, V
FO
= 15V*
—
10
15
mA
Minimum Fault Output Pulse Width
t
FO
V
D
= 15V*
1.0
1.8
—
mS
* Fault output is given only when the internal SC, OT, and UV protections circuits of either an upper-arm or a lower-arm device operate to protect it.
