PM20CSJ060
Intellimod™ Module
Three Phase IGBT Inverter Output
20 Amperes/600 Volts
470
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings,
T
j
= 25
°
C unless otherwise specified
Characteristics
Symbol
PM20CSJ060
Units
Power Device Junction Temperature
T
j
-20 to 150
°
C
Storage Temperature
T
stg
-40 to 125
°
C
Case Operating Temperature
T
C
-20 to 100
°
C
Mounting Torque, M4 Mounting Screws
—
13
in-lb
Module Weight (Typical)
—
60
Grams
Supply Voltage Protected by OC and SC (V
D
= 13.5 - 16.5V, Inverter Part)
V
CC(prot.)
400
Volts
Isolation Voltage, AC 1 minute, 60Hz Sinusoidal
V
RMS
2500
Volts
Control Sector
Supply Voltage Applied between (V
UP1
-V
UPC
, V
VP1
-V
VPC
, V
WP1
-V
WPC
, V
N1
-V
NC
)
V
D
20
Volts
Input Voltage Applied between (U
P
, V
P
, W
P
, U
N
, V
N
, W
N
)
V
CIN
20
Volts
Fault Output Supply Voltage (Applied between F
O
and V
C
)
V
FO
20
Volts
Fault Output Current
I
FO
20
mA
IGBT Inverter Sector
Collector-Emitter Voltage (V
D
= 15V, V
CIN
= 15V)
V
CES
600
Volts
Collector Current,
±
I
C
20
Amperes
Peak Collector Current,
±
I
CP
40
Amperes
Supply Voltage (Applied between P - N)
V
CC
450
Volts
Supply Voltage, Surge (Applied between P - N)
V
CC(surge)
500
Volts
Collector Dissipation
P
C
56
Watts
