Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Intellimod™ Module
Single Phase
IGBT Inverter Output
600 Amperes/600 Volts
PM600DSA060
Outline Drawing and Circuit Diagram
635
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
□
Complete Output Power
Circuit
□
Gate Drive Circuit
□
Protection Logic
– Short Circuit
– Over Current
– Over Temperature
– Under Voltage
Applications:
□
Inverters
□
UPS
□
Motion/Servo Control
□
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM600DSA060 is a 600V,
600 Ampere Intellimod™ Intelligent
Power Module.
Type
Current Rating
V
CES
Amperes
Volts (x 10)
PM
600
60
Dimensions
Inches
Millimeters
A
5.12
130.0
B
4.33
±
0.010
110.0
±
0.25
C
3.54
90.0
D
2.76
±
0.010
70.0
±
0.25
E
1.61
41.0
F
1.34 +0.04/-0.02 34.0 +1/-0.5
G
1.22
31.0
H
1.10
28.0
J
1.06
27.0
Dimensions
Inches
Millimeters
K
0.71
18.0
L
0.57
14.5
M
0.53
13.5
N
0.51
13.0
P
M8 Metric
M8
Q
0.28
7.0
R
0.26 Dia.
Dia. 6.5
S
0.100
2.54
T
0.08 Dia.
Dia. 2.0
G
Q
F
L
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
SNR
VNC
FNO
VN1
CN1
VP1
SPR
CP1
VPC
FPO
N SIDE
P SIDE
M
0.64 MM SQ. PIN
(10 TYP.)
B
K
D
C
A
J
H
H
N
E
1
P
C2E1
E2
C1
23
4
5
P - M8 THD.
(3 TYP.)
R - DIA.
(4 TYP.)
T - DIA.
(2 TYP.)
12
3
4
5
N
S - (8 TYP.)
SINK
SENS
OUT2
OUT1
GND
TEMP
VCC
FO
SR
IN
VN1
FNO
SNR
CN1
VNC
C2E1
E2
SINK
SENS
OUT2
OUT1
GND
TEMP
VCC
FO
SR
IN
C1
VP1
FPO
SPR
CP1
VPC
