PM50RVA120
Intellimod™ Module
Three Phase + Brake IGBT Inverter Output
50 Amperes/1200 Volts
Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Thermal Characteristics
Characteristic
Symbol
Condition
Min.
Typ.
Max.
Units
Junction to Case Thermal Resistance
R
th(j-c)Q
Each Inverter IGBT
—
—
0.37
°C/Watt
R
th(j-c)D
Each Inverter FWDi
—
—
0.70
°C/Watt
R
th(j-c)Q
Each Brake IGBT
—
—
0.93
°C/Watt
R
th(j-c)D
Each Brake FWDi Part
—
—
1.50
°C/Watt
Contact Thermal Resistance
R
th(c-f)
Case to Fin Per Module,
—
—
0.027
°C/Watt
Thermal Grease Applied
Recommended Conditions for Use
Characteristic
Symbol
Condition
Value
Units
Supply Voltage
V
CC
Applied across P-N Terminals
≤ 800
Volts
V
CE(surge)
Applied across C-E Terminals
≤ 1000
Volts
V
D
Applied between V
UP1
-V
UPC
,
15 ± 1.5
Volts
V
N1
-V
NC
, V
VP1
-V
VPC
, V
WP1
-V
WPC
Input ON Voltage
V
CIN(on)
Applied between
≤ 0.8
Volts
Input OFF Voltage
V
CIN(off)
U
P
, V
P
, W
P
, U
N,
V
N,
W
N
, B
r
≥ 4.0
Volts
Arm Shoot-Through Blocking Time
t
DEAD
For IPM’s each Input Signal
≥ 3.0
µS
