www.vishay.com For technical questions, contact: [email protected] Document Number: 93095
2 Revision: 29-Jul-08
HFA32PA120C
Vishay High Power Products HEXFRED ®
Ultrafast Soft Recovery Diode, 2 x 16 A
ELECTRICAL SPECIFICATIONS PER LEG (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Cathode to anode
breakdown voltage
V
BR
I
R
= 100 µA 1200 - -
V
Maximum forward voltage V
FM
I
F
= 16 A
See fig. 1
- 2.5 3.0
I
F
= 32 A - 3.2 3.93
I
F
= 16 A, T
J
= 125 °C - 2.3 2.7
Maximum reverse
leakage current
I
RM
V
R
= V
R
rated
See fig. 2
- 0.75 20
µA
T
J
= 125 °C, V
R
= 0.8 x V
R
rated - 375 2000
Junction capacitance C
T
V
R
= 200 V See fig. 3 - 27 40 pF
Series inductance L
S
Measured lead to lead 5 mm from package body - 8.0 - nH
DYNAMIC RECOVERY CHARACTERISTICS PER LEG (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time
See fig. 5, 10
t
rr
I
F
= 1.0 A, dI
F
/dt = 200 A/µs, V
R
= 30 V - 30 -
ns t
rr1
T
J
= 25 °C
I
F
= 16 A
dI
F
/dt = 200 A/µs
V
R
= 200 V
- 90 135
t
rr2
T
J
= 125 °C - 164 245
Peak recovery current
See fig. 6 I
RRM1
T
J
= 25 °C - 5.8 10
A
I
RRM2
T
J
= 125 °C - 8.3 15
Reverse recovery charge
See fig. 7 Q
rr1
T
J
= 25 °C - 260 675
nC
Q
rr2
T
J
= 125 °C - 680 1838
Peak rate of fall of recovery
current during t
b
See fig. 8
dI
(rec)M
/dt1 T
J
= 25 °C - 120 -
A/µs
dI
(rec)M
/dt2 T
J
= 125 °C - 76 -
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Lead temperature T
lead
0.063" from case (1.6 mm) for 10 s - - 300 °C
Thermal resistance,
junction to case
R
thJC
- - 0.83
K/W
Thermal resistance,
junction to ambient
R
thJA
Typical socket mount - - 80
Thermal resistance,
case to heatsink
R
thCS
Mounting surface, flat, smooth and greased - 0.50 -
Weight
- 2.0 - g
- 0.07 - oz.
Mounting torque
6.0
(5.0)
-
12
(10)
kgf · cm
(lbf · in)
Marking device Case style TO-247AC (JEDEC) HFA32PA120C
