C&H Technology Phawo...kS.. - Manual (Page 4)

Document Number: 13057
Revision 28-Mar-02
www.vishay.com
18
Phawo...kS..
Vishay ESTA
F
N
U
N
Q
N
C
N
I
N
CASING H
(Hz) (V) (kVAr) (µF) (A) CONDUCTIVE GROUNDED (mm)
2000 250 500 637 2000 X X 450
250 660 840 2640 X 550
600 1200 265 2000 X X 350
600 1600 354 2667 X 400
750 1500 212 2000 X X 350
750 2000 283 2667 X 400
1000 2000 159 2000 X X 300
1000 2650 211 2650 X 350
1500 3000 106 2000 X X 350
1500 3975 141 2650 X 450
2000 4000 80 2000 X X 450
2000 5300 105 2650 X 550
2400 4800 66 2000 X X 600
2400 6360 88 2650 X 700
3000 250 480 407 1920 X X 350
250 660 560 2640 X 400
600 1160 171 1933 X X 300
600 1600 236 2667 X 350
750 1470 139 1960 X X 250
750 2000 189 2667 X 350
1000 1950 104 1950 X X 300
1000 2650 141 2650 X 350
1500 2940 69 1960 X X 300
1500 3960 93 2640 X 350
4000 250 470 299 1880 X X 300
250 660 420 2640 X 350
600 1120 124 1867 X X 250
600 1600 177 2667 X 350
750 1400 99 1867 X X 250
750 1980 140 2640 X 300
1000 1900 76 1900 X X 250
1000 2650 105 2650 X 300
1500 2840 50 1893 X X 250
1500 3960 70 2640 X 300
5000 250 460 234 1840 X X 250
250 640 326 2560 X 300
600 1100 97 1833 X X 250
600 1520 134 2533 X 300
1000 1850 59 1850 X X 250
1000 2560 81 2560 X 250
1500 2770 39 1847 X X 300
1500 3840 54 2560 X 350
8000 250 420 134 1680 X X 250
250 600 191 2400 X 250
600 1040 57 1733 X X 200
600 1420 78 2367 X 250
1000 1740 35 1740 X X 250
1000 2400 48 2400 X 300
1500 2600 23 1733 X X 250
1500 3500 31 2333 X 300
10000 250 420 107 1680 X X 250
250 570 145 2280 X 300
500 850 54 1700 X X 200
500 1140 73 2280 X 250
600 1020 45 1700 X X 200
600 1360 60 2267 X 250
750 1275 36 1700 X X 200
750 1720 49 2293 X 250
1000 1700 27 1700 X X 200
1000 2300 37 2300 X 250
1500 2550 18 1700 X X 250
1500 3400 24 2267 X 300
Shown are the maximum power ratings, other power ratings, voltages, and frequencies on request.
Medium Frequency Capacitors Water Cooled
150-10000Hz SUBDIVIDED IN PARTIAL OUTPUTS
