Three Phase, 25A Panel Mount Solid State Relay Assembly
- Zero or Random Crossing
- Input Voltages: 90-280
VAC
, 3-32
VDC
- Overvoltage and Transient Protection
- Output Voltages:24-280
VAC
, 48-660
VAC
- .6 °C/W Heat Sink Thermal Resistance
Load Current at Ambient
Part Number Input Range Output Range 45-70C 75C 80C
CHASS3R25N24-90… 90-280 VAC 24-280 VAC 25A 23A 20A
CHASS3R25N24-3… 3-32 VDC 24-280 VAC 25A 23A 20A
CHASS3R25N48-90… 90-280 VAC 48-660 VAC 25A 23A 20A
CHASS3R25N48-3… 3-32 VDC 48-660 VAC 25A 23A 20A
Note: Add the letter “Z” at the end of the part number to indicate zero crossing or “R”
for random. Random SSR’s are available with a 3-32 VDC input only.
