Phase Control Thyristors
(Stud Version), 300 A
ST300SPbF Series
Vishay High Power Products
FEATURES
• Center amplifying gate
• International standard case TO-209AE (TO-118)
• Hermetic metal case with ceramic insulator
• Threaded studs UNF 3/4"-16UNF-2A or ISO M24 x 1.5
• Compression bonded encapsulation for heavy duty
operations such as severe thermal cycling
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
300 A
TO-209AE (TO-118)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
300 A
T
C
75 °C
I
T(RMS)
470
A
I
TSM
50 Hz 8000
60 Hz 8380
I 2 t
50 Hz 320
kA 2 s
60 Hz 292
V
DRM
/V
RRM
400 to 2000 V
t
q
Typical 100 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM REPETITIVE PEAK
AND OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST300S
04 400 500
50
08 800 900
12 1200 1300
16 1600 1700
18 1800 1900
20 2000 2100
