Document Number: 94413 For technical questions, contact: [email protected] www.vishay.com
Revision: 06-May-08 1
Phase Control Thyristors
(Hockey PUK Version), 910 A
ST700CLPbF Series
Vishay High Power Products
FEATURES
• Center amplifying gate
• Metal case with ceramic insulator
• International standard case TO-200AC (B-PUK)
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
910 A
TO-200AC (B-PUK)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
910 A
T
hs
55 °C
I
T(RMS)
1857 A
T
hs
25 °C
I
TSM
50 Hz 15 700
A
60 Hz 16 400
I 2 t
50 Hz 1232
kA 2 s
60 Hz 1125
V
DRM
/V
RRM
1200 to 2000 V
t
q
Typical 150 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM REPETITIVE PEAK
AND OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST700C..L
12 1200 1300
80
16 1600 1700
18 1800 1900
20 2000 2100
