Fixed Wirewound Enamelled Corrugated Tape Resistors
Very High Dissipation
www.vishay.com
For technical questions, contact: [email protected]
Document Number: 50018
64
Revision: 18-Dec-06
RSO
Vishay Sfernice
FEATURES
•
160 Watt to 1 kW at 25 °C
The remarkable dissipation power of this series is the result of an original winding method using corrugated edge-wound tape,
thus forming a very active radiator. The enamelling follows the contour of the resistive element and provides effective insulation
and support for the winding.
The tubular core is of special ceramic, capable of withstanding high thermal shock and overload of short duration.
DIMENSIONS
CS Collars
AN Collars
A
Z
F
P
ØB
ØQ
R
ØC
ØC
D
E
SCREWED STAINLESS STEEL 304 L “AN” TYPE 1
A
26
ØB
J
K
ØC
M
G
H
15
L
SCREWED STAINLESS STEEL 304 L “CS” TYPE 1
A
23
3
ØB
58
ØC
J
K
M
G
H
15
L
SCREWED STAINLESS STEEL 304 L “CS” TYPE 2
DIMENSIONS in millimeters
RSO STYLE
25 x 138
25 x 168
30 x 250
40 x 370
50 x 373
Connections
AN
type 1
AN
type 1
AN
type 1
AN
type 2
AN
type 2
CS
type 1
CS
type 1
CS
type 1
CS
type 2
CS
type 2
A ± 2
138
168
250
370
373
Ø B max.
39
39
44
54.5
65
Ø C min.
12.6
12.6
17.4
22.3
27.1
D max.
54
54
62
85.8
97
E
33.5 ± 1
33.5 ± 1
36 ± 1
57 ± 1.5
63 ± 1.5
F + 0.5
+ 0
9
9
13
18
18
Z
6
6
5
10
11.5
G - 4
- 0
199
229
317
432
432
H - 4
- 0
169
199
287
405
405
J
50 ± 1.5
50 ± 1.5
60 ± 1.5
73.8
79
K
27 ± 1
27 ± 1
30 ± 1
45 ± 1.5
45 ± 1.5
L ± 0.5
6.5
6.5
9
9
9
M ± 0.5
24
24
25
30
30
P
117 ± 2
147 ± 2
227 ± 2.5
332 ± 3
332 ± 3
Q
5.7
5.7
5.7
9.2
9.2
R
28.5 ± 1
28.5 ± 1
31 ± 1
45 ± 1.5
51 ± 1.5
Average
weight
in g
AN
160
190
350
960
1375
CS
205
235
400
1040
1455
