MITSUBISHI ELECTRIC CORPORATION
HIGH VOLTAGE DIODE MODULE HVM-2001-A (HV-SETSU)
PAGE
4 / 11
11. Test Circuit & Definition of Switching Characteristics
V
CC
C = 2 mF
L
S1
= 500 nH
L
S2
= 100 nH
C
S
= 200 uF
L
LOAD
Rg
DUT: diode
K
A
Fig. 1 – Switching test circuit
Diode part: reverse recovery
0
0
if dt
0
t6
Qrr = –
∫
I
F
di/dt
Irr
dt
di
10%V
R
10%I
F
t5
50%Irr
90%Irr
trr
t6
V
R
t6
t5
if•vr dt Erec = –
∫
0
Fig. 2 – Definitions of reverse recovery charge & energy
