Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272 Intellimod™ Module
Three Phase
IGBT Inverter Output
100 Amperes/600 Volts
1
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
£
Complete Output Power
Circuit
£ Gate Drive Circuit
£ Protection Logic
– Short Circuit
– Over Temperature
– Under Voltage
Applications:
£
Inverters
£ UPS
£ Motion/Servo Control
£ Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM100CVA060 is a 600V,
100 Ampere Intellimod™ Intelligent
Power Module.
Type Current Rating V
CES
Amperes Volts (x 10)
PM 100 60
Outline Drawing and Circuit Diagram
Dimensions Inches Millimeters
A 4.33 110.0
B 3.50 89.0
C 0.87 +0.04/-0.02 22.0 +1.0/-0.5
D 3.74±0.010 95.0±0.25
E 2.91±0.010 74.0±0.25
F 0.16 4.0
G 0.87 22.0
H 0.42 10.6
J 0.79 20.0
K 2.99±0.02 76.0±0.5
L 0.39 10.0
M 0.49 12.5
N 0.67 17.0
Dimensions Inches Millimeters
P 0.30 7.5
R 0.65 16.5
S M5 Metric M5
T 0.22 Dia. Dia. 5.5
U 0.56±0.010 14.1±0.25
V 1.72±0.012 43.57±0.3
W 0.57±0.012 14.6±0.3
X 2.90 73.7
Y 0.78 19.7
Z 0.10±0.010 2.54±0.25
AA 1.37±0.010 3.49±0.25
BB 0.02 SQ 0.64 SQ
CC 0.12 +0.04/-0.02 3.0 +1.0/-0.5
PM100CVA060
S NUTS (6 TYP.)
T (4 TYP.)
D P
A
B K E
1 2 3 4
5 6 7 8
9 10 1112
13 14 15 16
17 18 19
N P B
U V W
J
TYP.
N
V
U
R
P
U
M
L - TYP.
M
C G
F
H
Y
X W
Z - TYP.
AA - TYP.
BB SQ PIN - TYP.
(19 PLACES)
CCØ
(4 PLACES)
TERMINAL CODE
1. W
FO
2. V WPC
3. W P
4. V WP1
5. V FO
6. V VPC
7. V P
8. V VP1
9. U FO
10. V UPC
11. U P
12. V UP1
13. Br
14. F
O
15. VNC
16. VN1
17. UN
18. VN
19. WN
DETAIL A
SEE
DETAIL A
OUT
TEMP
Si
GND
VN1 WN VNC
F
O
NC
W V U P
Rf O
V CC
F O
IN
TH
GND
OUT
Si
GND
VN
V CC
F O
IN
GND
OUT
Si
GND
UN
V CC
F O
IN
GND
OUT
Si
GND
V
WP1 W
P
W
FO
V
FO
U
FO
V
WPC
V CC
F O
IN
GND
OUT
Si
GND
V
VP1 V
P
V
VPC
V CC
F O
IN
GND
OUT
Si
GND
V
UP1 U
P
V
UPC
V CC
F O
IN
GND
N NC
Rf O = 1.5k OHM
