Intellimod™ Module
Half Phase
IGBT Inverter Output
600 Amperes/1200 Volts
PM600HSA120
683
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
□
Complete Output Power
Circuit
□
Gate Drive Circuit
□
Protection Logic
– Short Circuit
– Over Current
– Over Temperature
– Under Voltage
Applications:
□
Inverters
□
UPS
□
Motion/Servo Control
□
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM600HSA120 is a 1200V,
600 Ampere Intellimod™ Intelligent
Power Module.
Type
Current Rating
V
CES
Amperes
Volts (x 10)
PM
600
120
Dimensions
Inches
Millimeters
A
5.24
133.0
B
4.33
±
0.01
110.0
±
0.25
C
3.98
101.0
D
3.23
±
0.01
82.0
±
0.25
E
2.16
55.0
F
1.97
50.0
G
1.42 +0.04/-0.02 36.0 +1.0/-0.5
H
1.42
36.0
J
1.33
33.7
K
1.25
31.7
L
1.02
26.0
M
0.80
20.3
N
0.79
20.0
Dimensions
Inches
Millimeters
P
0.71
18.0
Q
0.41
10.5
R
0.37
13
.5
S
0.35
9.0
T
M8 Metric
M8
U
0.28
7.0
V
0.26 Dia.
Dia. 6.5
W
0.02
5.0
X
0.02 Dia.
Dia. 5.0
Y
0.100
2.54
Z
0.09 Dia.
Dia. 2.3
AA
0.04 Dia.
Dia. 1.0
Outline Drawing and Circuit Diagram
1.
2.
3.
4.
5.
V1
SR
C1
VC
FO
SINK
SENS
OUT2
OUT1
GND
TEMP
VCC
FO
SR
IN
E
C
V1
FO
SR
C1
VC
FIGURE A
J
G
U
SEE FIGURE A
R
0.64 MM SQ. PIN
(5 TYP.)
P
F
W
E
E
B
A
C
S
S
K
N
M
H
D
H
L
E
C
12
3
4
5
Y - (4 TYP.)
V - DIA.
(4 TYP.)
T - M8 THD
Z
AA
X
Q
- DIA.
- DIA.
- DIA.
