ASSISTANT AH-1960 User Manual
Miniweather forecast station, Model ah-1960

Warranty period
Гарантийный срок
Date of sale
Дата продажи
Model
Номер модели
Stamp
Печать магазина
O P E R A T I O N M A N U A L
MINIWEATHER
FORECAST STATION
Model AH-1960
FEATURES
•
Weather Forecast with Sunny, Slightly Cloudy, Cloudy, Rainy and Cloud
Burst.
•
Measuring range:
Indoor temperature: 0°C ~ +50°C
Humidity: 30 % ~ 90 %
Outdoor temperature: – 50°C ~ +70°C
•
Temperature Alert function.
•
Max/Min Memory for Humidity, Indoor and Outdoor Temperature.
•
Moon Phase and Tide Display.
•
Perpetual Calendar Up to Year 2069.
•
12/24Hour time display selectable.
•
Wall Mount or Table Stand Selectable.
•
Battery: DC 1.5 V AA size x 2 pcs
•
Size: 160 x 92 x 26 mm
APPEARANCE
Part A – LCD
A1: Weather Forecast
A2: Barometer Pressure Trend
A3: Outdoor Temperature
A4: Outdoor Temperature Trend.
A5: Indoor Temperature.
A6: Indoor Humidity
A7: Moon Phase & Tide Indication
A8: Time Display
Part B – Buttons
B1: [ALARM] button
B2: [ALERT] button.
B3: [MODE] button
B4: [SNOOZE/LIGHT] button
B5: [WEATHER] button
B6: [MAX/MIN] button
B7: [+ (12/24)] button
B8: [- (C/F)] button
B9: [RESET] button
Part C – Structure
C1: Wall Mount Hole
C2: Battery Compartment
C3: Outdoor Temperature Probe.
C4: Removable Stand
SET UP
•
Insert batteries.
•
Use a pin to press the [RESET] (B9) button
WEATHER FORECAST FUNCTION
•
After Batteries inserted, or holding [WEATHER] button (B5) for 3 seconds,
weather icon Flash (LCD-A1). Enter the current weather status by pressing
[+] (B7) or [–] (B8) buttons. Press [MODE] button (B3) to confirm the setting.
The weather forecast may not be accurate if the current weather entered is
not correct.
•
The weather station will start the first forecast at 6 hours later after the
current weather status is entered. Totally 5 different weather status symbols in
the weather forecast. They are forecasting the weather in future.
«
» means Sunny.
«
» means Slightly Cloudy.
«
» means Cloudy.
«
» means Rainy
«
» means Cloudburst.
•
If there is any inconsistency of weather forecast between Local Weather
Station and this unit, the Local Weather Station’s forecast should prevail.
We will not held responsible for any trouble that may come up due to wrong
forecasting from this unit.
•
The trend pointer displayed on the LCD (A2) indicates the trend of the
Barometric pressure.
«
» indicates the barometric pressure trend is increasing.
«
» indicates the barometric pressure trend is steady.
«
» indicates the barometric pressure trend is decreasing.
TIME SETTING
•
Hold [MODE] button (B3) for 3 seconds to enter Clock/Calendar setting
Mode.
•
Press [+] (B7) or [-] (B8) buttons to adjust the setting and press [MODE]
(B3) button to confirm each setting.
•
The setting sequence is shown as follow: Hour, Minutes, Second, Year,
Month/Day sequence, Month, Day, Time Zone, Day-of-week language.
•
8 languages can be selected in Day-of-week, they are: German, English,
Russian, Denmark, Dutch, Italian Spanish and French,. The languages and
their selected abbreviations for each day of the week are shown in the fol-
lowing table.
LANGUAGE
SUNDAY MONDAY TUESDAY WEDNESDAY THURSDAY FRIDAY SATURDAY
GERMAN, GE
SO MO DI
MI
DO FR SA
ENGLISH, EN
SU MO TU WE
TH FR SA
RUSSIAN, RU
BC
ПH BT CP
ЧT
ПT CБ
DENMARK, DA
SO
MA
TI
ON
TO
FR
LO
DUTCH, NE
ZO MA DI WO DO VR ZA
ITALIAN, IT
DO LU MA ME GI VE SA
SPANISH, ES
DO LU MA MI
JU VI SA
FRENCH, FR
DI LU MA ME
JE VE SA
•
The Time Setting Mode will automatically exit in 5 seconds without any
adjustment.
SNOOZE ALARM CLOCK FUNCTION
•
Press [MODE] button (B3) to select to view:
Time
→
Date/Month /Weekday
→
Alarm Time («ALM» Shown on the LCD)
•
When viewing the Alarm Time, hold [MODE] button for 3 seconds to
enter Alarm Time setting. Press [+] (B7) or [-] (B8) buttons to adjust the
alarm time.
•
Press [ALARM] button (B1) to switch alarm on or off. If it is on, «
»
shown on the LCD.
•
If [SNOOZE/LIGHT] button (B4) is pressed during alarming, the alarm will
pause and alarm again in 5 minutes later. This snooze alarm can be repeated
for maximum 7 times. Then the alarm will stop.
•
Or press other button to stop the snooze alarm.
MAXIMUM/MINIMUM INDOOR /OUTDOOR
TEMPERATURE AND HUMIDITY RECORDING
FUNCTION
•
Press [MAX/MIN] button (B6) to show the maximum recorded Indoor
/Outdoor Temperature and Humidity reading.
«
» is shown on the LCD
•
Press [MAX/MIN] button (B6) again to show the minimum recorded
Indoor/Outdoor Temperature and Humidity reading.
«
» is shown on the LCD.
•
Hold [MAX/MIN] button (B6) for 3 seconds to clear the recorded maximum
and minimum reading.
THERMOMETER
•
Press [- (C / F)] button (B9) to select Indoor/Outdoor Temperature in Celsius
mode/Fahrenheit mode.
THE USE OF OUTDOOR TEMPERATURE PROBE
•
Put the metal casing outside and leave the main unit in a indoor area to
avoid freezing up the battery when the outdoor temperature is between the
following range: - 50 °C ~ 0°C and +50°C ~ + 70°C
•
The trend pointer displayed on the LCD (A4) indicates the trend of the
outdoor temperature.
«
» indicates the outdoor temperature is increasing.
«
» indicates the outdoor temperature is steady.
«
» indicates the outdoor temperature is decreasing.
TEMPERATURE ALERT FUNCTION
•
Hold [ALERT] button (B2) for 3 seconds to enter Temperature Alert setting,
Temperature’s digits flash.
•
Press [+] (B7) or [-] (B8) button to select Indoor or Outdoor temperature
alert. Press [ALERT] button (B3) to confirm the setting.
•
Press [+] (B7) or [-] (B8) button to set the upper «
» and lower «
» limit
of the temperature. Press [ALERT] button (B3) to confirm the setting.
•
Press [ALERT] button (B3) to set the Temperature Alert function on or off
(«
» appears on the LCD if this function is on).
MOON PHASE & TIDE DISPLAY
The Moon Phase of each day is shown on the LCD
A: New Moon
B: Waxing Crescent
C: First Quarter
D: Waxing Gibbous E: Full Moon
F: Waning Gibbous
G: Last Quarter
H: Waning Crescent
Tide Status
H: High Tide
M: Medium Tide
L: Low Tide
BACK LIGHT
•
Press [SNOOZE/LIGHT] button (B4), back light states for 5 seconds.
Note:
•
Use a pin to press the reset button if the Unit does not work properly.
•
The clock loses its time information when the battery is removed.
•
All Setting Mode will automatically exit in 5 seconds without any adjustment.
TABLE OF INACCURACY
Value
Accuracy
Thermometer
– 10 ~ 0 °C
± 2 °C
0 ~ +40 °C
+/-1C
+40 ~ +50 °C
+/-2C
Hygrometer
40 % – 80 %
+/-5 %
25 % – 40 %
+/-7%
80% – 95%
+/-7%
