Deflecto DVBOXPC - Manual

Technical Product Specifications
Performance Data
for dryer venting box
Material
• white high-impact polystyrene
M Me ee etts s U UL L S Stta an nd da arrd d 9 94 4H HB B T Te es stts s ffo orr F Flla am mm ma ab biilliitty y
General Information
• saves space
– recessed design for placement
behind drywall
– allows dryer to sit 4-6” closer to wall
• improves dryer efficiency
– ensures a direct path between dryer and
vent resulting in better air flow, reduced
energy bills
• reduces fire hazard
– no more kinks that result in lint build-up
which can lead to fires
• ensures clean appearance
– eliminates exposed drywall cuts
• installs easily
– regardless of distance between studs, the
mounting straps may be adjusted to ensure
a stable, permanent installation
– mounts in up or down postiton
Model No. Description
Dryer Venting Box
DVBOXPC Dryer Venting Box
Maximum Installation Width: 20 3 /
4
”
Depth: 4 ”
H
eight: 17
5
/ 16
”
7 3 /
8
”
3 3 /
4
”
Width: 10 1 /
4
”
H
eight: 17
1
/ 4
”
Width: 11 1 /
2
”
O Ov ve erra allll D Diim me en nssiio on nss
w wiitth ho ou utt F Fiin niissh h
T Trriim m P Plla atte e
D Diim me en nssiio on nss
o off F Fiin niissh h
T Trriim m P Plla atte e
