9.2 D

imensions

ø 107 mm

(4.21")

234 mm / 223 mm

(9.21" / 8.78")

ø 125 mm

(4.92")

ø 165 mm

(6.5")

DN 50 PN16

152,5 mm

(6.00")

101,5 mm

(3.99")

ø 48 mm

(1.89")

140 mm

(5.51")

Clamp 3" / DN 65

ø 91 mm (3.58")

Fig. 10: Dimensions of swivelling quick-release fastener for VEGAPULS 66.

20

Swivelling quick release fasterner • for VEGAPULS 66 Clamp 3"

9 Supplement

41775

-EN

-121018
