6.3 B

ring the radar sensor back into position

"Operation"

Proceed as follows:

1

Press down the clamping sleeve and keep it pressed

2

Swivel in the swivelling part with radar sensor and push downward

3

Release the clamping sleeve

4

Plug in the lock bolt

Radar sensor is in position "Operation".

Swivelling quick release fasterner • for VEGAPULS 66 Clamp 3"

15
