4 Mounting

Electronics module • VEGABAR series 80

45054-EN-131119

Note:

Make sure that the housing is not rotated during the electronics ex-

change. Otherwise the plug may be in a different position later.
6. Insert the new electronics module carefully. Make sure that the

plug is in the correct position.

7. Screw in the two holding screws and tighten them
8. Attach the terminal blocks according to the operating instructions

manual of the respective sensor

9. Screw the housing cover back on
The electronics exchange is now finished.
As a rule, an exchange of electronics must be documented internally

if Ex applications are involved.
