VEGAMIP 61, encapsulated horn anten-
na with PTFE cover
-40 … +200 °C (-40 … +392 °F)
-
VEGAMIP 61 with mounting adapter
150 mm (optional)
-40 … +250 °C (-40 … +482 °F)
-
VEGAMIP 61 with mounting adapter
300 mm (optional)
-40 … +450 °C (-40 … +842 °F)
Performance data
Emitted power < 3 mW
Max. power density in a distance of 1 m < 1 µW/cm²
Electromechanical data
Cable entry/plug (dependent on the version)
-
Single chamber housing l
1 x cable entry M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; attached 1 x cable
entry M20 x 1.5
or:
l
1 x cable entry ½ NPT, 1 x blind stopper ½ NPT,
1 x cable entry ½ NPT
or:
l
1 x plug M12 x 1; 1 x blind stopper M20 x 1.5
Spring-loaded terminals for wire cross-section up to 1.5 mm² (AWG 16)
Voltage supply
Operating voltage 20 … 253 V AC, 50/60 Hz, 20 … 72 V DC (at
U >
60 V DC, the ambient temperature can be max.
50 °C/122 °F)
Power consumption 2 VA (AC), approx. 0.8 W (DC)
Electrical protective measures
Protection rating IP 66/IP 67
Overvoltage category III
Protection class I
Approvals
Instruments with approvals can have different technical data depending on the version.
That's why the associated approval documents have to be noted with these instruments. They are
part of the delivery or can be downloaded under www.vega.com via "VEGA Tools" and "serial
number search" as well as via "Downloads" and "Approvals".
