9 Supplement
9 .1 Technical data
Technical data
Following you find all data deviating from the standard instrument. All other technical data are
specified in the operating instruction of the respective sensor.
General data
Material 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
-
Float PVC
-
Nut 316 Ti (1.4571)
Weights
-
Float approx. 2400 g (85 oz)
Point level sensors VEGASWING 63, conductive electrode EL 3
Suitable point level sensor - VEGASWING 63
-
Order length L - Point level sensor 140 mm (5.51 in)
-
Housing material Plastic (single chamber housing)
-
Process fitting G¾ A
Suitable point level sensor - EL 3
-
Order length L - Point level sensor 130 mm (5.12 in)
-
Number of rods 2
-
Housing material Stainless steel
-
Process fitting G1½ A
Process conditions
Process temperature -30 … +60 °C (-22 … +140 °F)
Approvals
The floating body can be used in Ex area zone 1 (ATEX II 2G).
There is a danger of static charging on the plastic floating body.
-
Avoid friction
-
No dry cleaning
-
Do not mount in areas with flowing,
non-conductive products
Float for oil/water detection • for VEGASWING 63 and EL 3 15
