12
5 Supplement
Antenna extension up to 450 °C • for VEGAPULS 62 and 68
38316-EN-131119
5.2 Dimensions
Antenna extension, one-piece
3
4
3
L1
y
y L gesamt / total
L
gesamt / tota
l
L
gesamt / tota
l
y L gesamt / total
y L gesamt / total
y L gesamt / total
y
L2
1
2
ø 48 mm
ø 95 mm
ø 75 mm
L1 + 120 mm
L1 + 216 mm
L1 + 287 mm
ш 2"
ш 4"
ш 3"
L1 + 4.72"
L1 + 8.5"
L1 + 11.23"
ø 48 mm
ø 95 mm
ø 75 mm
L2 + 120 mm
L2 + 216 mm
L2 + 287 mm
ш 2"
ш 4"
ш 3"
L2 + 4.72"
L2 + 8.5"
L2 + 11.23"
25 mm (0.98"
)
78,5 mm (3.09"
)
ø17,5 mm
(0.69")
Fig. 8: One-piece extension, with welded horn antenna. Dimensions L1, L2 according to order specification
1 Straight
2 Angled
3 Reference plane
4 Rinsing air connection
